The 3 Head Embroidery Machine is a multi-station commercial embroidery device engineered for medium-volume custom embroidery workshops. Unlike single-head embroidery equipment that only processes one piece at a time, this unit runs three independent embroidery stations synchronously. Operators can complete three identical embroidery products in a single production cycle, which directly lifts daily output without requiring multiple separate machines. It handles flat fabric embroidery, finished apparel embroidery and cap embroidery, covering most custom embroidery business demands such as brand logo embroidery, fashion pattern decoration and souvenir customization. Small and medium embroidery studios that receive steady bulk custom orders often select this commercial hat embroidery machine to boost production efficiency.
3 Head Embroidery Machine Parameters:
| Parameter | YS-1201CT (Single Head) | YS-1202CT (Two Heads) | YS-1203 (Three Heads) |
| Heads | 1 | 2 | 3 |
| Needles | 9 / 12 / 15 optional | 12 | 12 (9/15 optional) |
| Working Area | 360 × 510 mm | 400 × 500 mm | 400 × 450 mm |
| Max Speed | 1,000 RPM (adjustable) | 1,000 RPM (adjustable) | Flat: 1,000 RPM; caps/garments: 800 RPM |
| Control System | Dahao A15 | Dahao A15 | Dahao A15 |
| Display | Colour LCD touch, 1280×800 | Colour LCD touch, 1280×800 | 10 inch true colour touch LCD |
| Package Size (L×W×H) | 92×88×85 cm (wooden) | 1.37×1.12×0.92 m (wooden) | 2.07×1.12×1.01 m (wooden, ~2.3 CBM) |
| Gross Weight | 210 kg | 420 kg | 650 kg |
| Voltage | 110V/60Hz or 220V/50Hz | 110V/60Hz or 220V/50Hz | 110 220V |
| Spindle Motor | — | — | Servo motor |
| Rotary Hook | Standard | Standard | High quality hook |
Core Hardware Configuration of 3 Head Embroidery Machine
All parameters are derived from the standard configuration of the 3-head embroidery machine model, with a stable mechanical structure to support long-hour continuous production.
Three-station synchronous embroidery structure. Three independent embroidery heads run at the same rhythm. One operator can supervise all three stations at the same time, which optimizes labor efficiency in batch order processing.
Flexible needle configuration. It supports 12 needles as standard, with 9-needle and 15-needle options available. More needle positions support more color switching without manual rethreading, reducing pause time during continuous production.
Servo spindle motor + high-quality rotary hook. The servo motor delivers smooth power output and reduces vibration during high-speed operation. The premium rotary hook has higher durability than standard versions, adapting to long-term continuous working conditions.
Adjustable working speed. It reaches a maximum speed of 1000 RPM for flat fabric processing, and adjusts to 800 RPM for caps and finished garments. Operators can balance stitching accuracy and production speed according to material characteristics.
Wide voltage adaptation. It supports a 110V-220V power supply, adapting to the power grid standards of different countries and regions without additional voltage conversion equipment.
12 Needles Per Head: The Multi-Color Advantage
Each head on the YG YS-1203 carries 12 needles. This is not a random number—it has direct production implications.
- Fewer thread changes. A 12-needle system holds 12 thread colors at all times. Most commercial designs use 4-10 colors. The 3-head embroidery machine runs these designs start to finish without the operator stopping to change thread. On a 9-needle machine, a 10-color design requires at least one stop for thread change. On a 6-needle machine, it requires multiple stops.
- Automatic color change. When the design calls for a new color, the machine selects the correct needle and continues stitching. The operator does not need to intervene. This automation runs continuously across all three heads simultaneously.
- Consistent thread tension. Each needle has its own tension setting. Once set, the machine maintains consistent tension across all 12 needles. This means consistent stitch quality across all colors in the design.
- The daily production impact. A 10-color design on a 9-needle machine requires 1-2 stops per piece for thread changes. Each stop takes 2-3 minutes. Over a 100-piece order, this adds 3-5 hours of downtime. The 12-needle system eliminates this downtime entirely.
Commercial Hat Embroidery Machine: 400×450mm Working Area Per Head
The working area per head determines what products the multi-head embroidery machine can handle and what size designs it can run.
What fits in 400×450mm:
- Full jacket backs
- Shirt fronts and chest designs
- Cap fronts (with cap frame)
- Multiple small designs on one garment
- Home textiles like pillowcases and tablecloths
- Bag and accessory panels
The cap embroidery difference. The YS-1203 supports a 270-degree wide cap frame. This frame holds the curved cap surface flat, allowing the machine to stitch the full cap front from edge to edge. Shorter cap frames restrict design placement. The 270-degree coverage means larger designs on caps and better placement control.
Three garments at once. Each head has its own 400×450mm working area. The operator loads three garments—one under each head. All three stitch simultaneously. The working area is large enough for most commercial garment applications without repositioning.
Model Selection Reference: Single Head / Double Head / Three Head
Choose the appropriate number of heads according to your daily order volume and workshop scale.
- Single head (YS-1201CT): Suitable for start-up studios and sporadic small custom orders. It has a small footprint and low initial investment, and supports 9/12/15 needle options.
- Double head (YS-1202CT): Suitable for small workshops with steadily growing orders. It balances output and space occupation, and is a common transitional model for businesses from small to medium scale.
- Three head (YS-1203): Suitable for medium-volume mixed production workshops. As a cost-effective multi-head embroidery machine, it achieves higher output under the same floor space and labor input.
Embroidery Sewing Machine For Sale
YG Machinery provides full-series commercial embroidery equipment with stable configuration and reliable performance. Every 3-head embroidery machine undergoes continuous operation testing before delivery to ensure stable performance under long-hour working conditions. We support flexible configuration selection and can customize the machine body color according to customer requirements. If you are looking for a reliable embroidery sewing machine for sale, or need to confirm the detailed parameters and configuration scheme of the equipment, send your daily order volume and main processing products to our team. We will provide you with targeted model recommendations and complete technical parameter information.
