A small track skid steer is a compact, highly maneuverable material handling machine built for work sites with limited space, uneven ground and frequently changing task demands. Unlike large loaders that require a wide operating room, this unit executes loading, unloading, site cleanup and auxiliary construction tasks efficiently in narrow zones. It applies to infrastructure construction, industrial facility maintenance, dock material handling, urban street renovation, residential building work, barn and livestock shed maintenance, and airport runway auxiliary work. It also works as reliable support equipment for large-scale engineering projects.
For contractors that handle scattered small-scale projects, a mini loader skid steer delivers better flexibility than bulky heavy equipment. Many site managers look for a compact skid steer for sale to expand their service scope for indoor and narrow-space jobs without investing in multiple machines.
Small Track Skid Steer Technical Specifications:
| Item | YG280 | YG380 | YG380C | |||
| With Rubber Track | With Chevron Engineering Tyre | With Chevron Engineering Tyre | ||||
| Metric | The U.S. | Metric | The U.S. | Metric | The U.S. | |
| Max working height(H3) | 2065mm | 81.3inch | 2143mm | 84.37inch | 2143mm | 84.37inch |
| Max pin height(H2) | 1803mm | 71inch | 1884mm | 74.17inch | 1884mm | 74.17inch |
| Max Dumping height(H1) | 1386mm | 54.6inch | 1488mm | 58.58inch | 1488mm | 58.58inch |
| Max Dumping distance(E) | 471mm | 18.5inch | 348mm | 13.7inch | 348mm | 13.7inch |
| Max Dumping Angle(a3) | 32° | 32° | 30° | 30° | 30° | 30° |
| Rollback of the bucket on the ground(a2) | 33° | 33° | 25° | 25° | 25° | 25° |
| Departure angle(a1) | 18° | 18° | 11° | 11° | 16° | 16° |
| Total height(H) | 1309mm | 51.5inch | 1233mm | 48.54inch | 1265mm | 50inch |
| Ground clearance(F) | 123mm | 4.8inch | 118mm | 4.65inch | 118mm | 4.65inch |
| Wheelbase(L1) | 690mm | 27.2inch | 636mm | 25.0inch | 636mm | 25.0inch |
| Overall length without bucket(L3) | 1778mm | 70inch | 1752mm | 69.0inch | 1980mm | 78inch |
| Total width(W) | 800mm | 31.5inch | 1160mm | 45.67inch | 1160mm | 45.67inch |
| Bucket width(B) | 820mm | 32.3inch | 980mm | 38.6inch | 980mm | 38.6inch |
| Total length with bucket(L) | 2210mm | 87inch | 2206mm | 86.9inch | 2430mm | 95.7inch |
| Turn radius forward turning(R) | 1237mm | 48.7inch | 1307mm | 51.5inch | 1307mm | 51.5inch |
Advantages of Small Track Skid Steer
This small track skid steer equipment stands out from conventional small loaders in four key aspects, all validated by actual on-site working data.
1. Ultra-compact footprint for confined work zones
The narrow body design allows the machine to enter narrow passages, indoor workshops and livestock barns that large loaders cannot access. The smallest model features an 800mm total width, which fits through most standard narrow doorways without disassembly. This capability greatly expands applicable scenarios for indoor renovation and confined-space construction.
2.360-degree free body rotation
The full in-place rotation function lets operators adjust machine orientation without extra reversing space. This feature brings huge convenience for outdoor work in tight areas, and reduces the time wasted on position adjustment during frequent task switching.
3. Strong terrain adaptability
Multiple walking system options match different ground conditions. High ground clearance keeps the chassis stable when crossing small obstacles and uneven ground. A compact track skid steer with rubber tracks delivers even lower ground pressure, making it suitable for soft soil and easily damaged ground surfaces.
4. Heavy-duty, durable construction
The small track skid steer body uses thickened high-quality steel with plastic spray surface treatment, which delivers strong rust and corrosion resistance for long-term outdoor work. Internationally renowned brand reducers ensure smooth transmission and high operational reliability, reducing unexpected downtime on construction sites.
Height and Reach: What the Numbers Mean
Maximum dumping height is the height at which the bucket dumps material. The YG280 reaches 1386mm—sufficient for loading into small dumpsters, trailers, and hoppers. The YG380 and YG380C reach 1488mm, providing better clearance for larger trucks.
- Maximum pin height is the height of the bucket hinge point. The YG280 reaches 1803mm. The YG380 and YG380C reach 1884mm. This extra height allows the operator to stack material higher and load into taller containers.
- Maximum working height is the total height of the machine with the bucket fully raised. The YG280 reaches 2065mm. The YG380 and YG380C reach 2143mm. This is the height the machine can reach when dumping into a high-sided truck or container.
- The dumping distance of 471mm (YG280) and 348mm (YG380/380C) determines how far the bucket extends when dumping. The YG280 reaches further forward, allowing more precise placement of material.
Rubber Track vs Engineering Tyre: On-Site Selection Guide
Many buyers feel confused when choosing between track and tyre configurations. The right choice directly affects work efficiency and equipment service life. We sort out clear adaptation boundaries based on actual site conditions.
Choose rubber track models when:
Your work sites are mostly soft soil, muddy ground or lawn surfaces that are easily damaged. Rubber tracks distribute machine weight evenly, reducing ground pressure and avoiding rutting on soft ground. They also generate less vibration during operation, which is suitable for indoor construction and work near residential areas.
Choose engineering tyre models when:
Most of your work takes place on hardened roads, factory floors or dock pavements. Tyre chassis supports faster travel speed between work zones, and daily maintenance is simpler and lower-cost. Chevron pattern tyres also deliver reliable grip on slightly wet paved surfaces.
Compact Skid Steer For Sale
A well-matched small track skid steer can greatly narrow the efficiency gap between large machinery and manual work in confined spaces. From ultra-narrow indoor renovation to outdoor municipal maintenance, from soft soil construction sites to hardened factory yards, this equipment delivers flexible and reliable performance through diversified model configurations and walking system options. Whether you need a compact track skid steer for soft-ground jobs or a tyre-based model for paved site work, our product lineup can match your actual requirements.
If you are looking for a durable mini loader skid steer to expand your construction service scope, or want to get detailed parameters of a specific model, contact our team today. Send us your regular working scenarios, site dimension limits and handling requirements, and we will provide professional configuration suggestions and full specification documents promptly.
