A commercial electric charging station, also known as an EV charging pile or commercial charging facility, is a professional device dedicated to charging electric vehicles and plug-in hybrid vehicles. It connects to the vehicle’s charging port via a dedicated cable, transmitting electrical energy to the vehicle’s battery to meet daily fast charging needs. As the global demand for new energy vehicles continues to rise, the demand for reliable, high-power charging infrastructure for commercial sites is growing rapidly, making it an essential supporting facility for the new energy vehicle industry. YG series commercial electric charging stations offer 3 standardized models with 60KW, 80KW, and 120KW rated power, equipped with smart touch control, multiple charging modes, and comprehensive safety protections to fit diverse commercial operation needs. For more details, contact the YG team today.
Commercial Electric Charging Stations Parameter:
| Product number | YG-60KW | YG-80KW | YG-120KW | |
| Detailed specification | rated power | 60KW | 80KW | 120KW |
| Charging equipment | User Interface | 7-inch LCD color display touchscreen | ||
| installation | Floor-standing/Down in down out | |||
| Routing mode device size | 635*423*1600(mm) | |||
| Input voltage | AC380V±20% | |||
| Input frequency | 45~65Hz | |||
| The output voltage | 200-750VDC | |||
| Single gun output current range | 200V-500V | 200V-500V | 200V-500V | |
| The output voltage | 0-90A | 0-120A | 0-160A | |
| Single gun output current range | 200V-750V | 200V-750V | 200V-750V | |
| The output voltage | 0-60A | 0-80A | 0-107A | |
| Charging equipment | Single gun output current range | 0-112A | 0-150A | / |
| Cable length | 5m | |||
| Electrical index | Measurement accuracy | Level 0.5 | ||
| Current limit protection value | ≥110% | |||
| Voltage regulation accuracy | ≤±0.5% | |||
| Steady flow accuracy | ≤±1% | |||
| Ripple coefficient | ≤±0.5% | |||
| effectiveness | ≥94.5% | |||
| Power factor | ≥0.99 (50% load or more) | |||
| Harmonic content THD | ≤5% (50% load or more) | |||
| Feature design | HMI | 7-inch LCD color display touch screen, LED indicator | ||
| Charging mode | Auto full / fixed power / fixed amount / fixed time | |||
| payment method | Credit card payment / APP payment /scan code payment | |||
| Communication Interface | Ethernet 2/3/4G (optional) | |||
| Safety design | Executive standard | GB\T 20234, GB/T 18487, GB/T 27930, NB\T 33008 | ||
| security function | Charge gun temperature detection, overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, over-temperature protection, low-temperature protection, insulation monitoring protection, polarity reverse connection protection, lightning protection, emergency stop protection, leakage protection | |||
| Environmental indicators | Operating temperature | -25°C~+50°C | ||
| Working humidity | 5%~95% non-condensing cream | |||
| Working elevation | <3000m | |||
| Protection level | IP54 | |||
| cooling method | Forced air cooling | |||
| Noise control | ≤60dB | |||
| MTBF | 100,000 hours | |||
Application of Commercial Electric Charging Stations:
1. Commercial Complex & Shopping Mall Parking Lots
Ideal for installation in shopping malls, supermarkets, and retail centers, providing charging services for customers’ electric vehicles, increasing customer stay time, and enhancing the competitiveness of commercial venues.
2. Logistics Parks & Commercial Fleet Depots
Designed for logistics companies, freight fleets, and new energy commercial vehicle teams, supporting fast charging for electric vans, light trucks, and distribution vehicles, ensuring the efficient daily operation of the fleet.
3. Office Buildings & Industrial Parks
Suitable for supporting facilities in office buildings, high-tech parks, and industrial zones, providing daily charging services for employees’ commuter vehicles and enterprise business vehicles, and improving the supporting level of the park.
4. Highway Service Areas & Transportation Hubs
Applied to highway service areas, bus stations, railway stations, and airport parking lots, providing fast charging services for long-distance travel vehicles and transit vehicles, solving the range anxiety of electric vehicle users.
5. Hotels & Cultural Tourism Scenic Spots
Perfect for hotels, resorts, scenic spots, and tourist camps, providing supporting charging services for tourists, enhancing the travel experience of new energy vehicle users, and increasing the attractiveness of the venue.
Features of YG Commercial Car Charging Stations:
1. Multi-Model High-Efficiency Fast Charging：60KW/80KW/120KW power options available, with up to 94.5% operating efficiency and 200V-750V wide voltage output, adapting to most electric passenger and commercial vehicles.
2. Smart Operation & Flexible Payment： Equipped with a 7-inch LCD touchscreen, supporting 4 charging modes and multiple payment methods (credit card/APP/scan code), with optional remote communication for easy management.
3. Full-Range Comprehensive Safety Protection： Built with 12+ safety protections, including overvoltage, short circuit, leakage, lightning, and over-temperature protection, fully ensuring the safety of the charging process.
4. Strong Environmental Adaptability & High Reliability： IP54 protection grade, stable operation in -25℃ to +50℃ environments, 100,000 hours MTBF, suitable for long-term indoor and outdoor commercial use.
5. Standard-Compliant & Easy Installation： Manufactured in line with mainstream international charging standards, compact floor-standing design with simple wiring for quick on-site installation, reducing deployment costs.
FAQ About Commercial Electric Charging Stations
A: Our 60KW, 80KW, and 120KW models support wide input voltage adaptation of AC380V±20% and 45-65Hz input frequency, fitting mainstream grid standards in most regions. We can provide professional grid capacity matching guidance based on your planned equipment quantity and existing site grid conditions, to help you avoid unnecessary grid transformation costs.
A: Yes, all our models support parallel networking and unified management. You can add more charging stations according to the growth of your site’s charging demand later, without replacing the original equipment or rebuilding the management system, which greatly reduces subsequent expansion costs and improves operation flexibility.
A: Our commercial electric charging stations support a wide DC output voltage range of 200V-750V, with high-precision voltage and current regulation, adapting to almost all mainstream brands of electric passenger cars, commercial vans, and light trucks on the market. The optimized charging control protocol can effectively avoid compatibility issues during charging.
A: Our commercial car charging stations are designed and manufactured in accordance with mainstream international charging standards, including GB/T 20234, GB/T 18487, GB/T 27930, and NB/T 33008. We can provide targeted configuration adjustments according to the access requirements of your target market, to ensure the equipment meets local regulatory and use standards.
Commercial EV Chargers For Sale–YG Machinery
YG series commercial electric charging stations integrate high-efficiency fast charging, smart operation, and comprehensive safety protection, providing reliable charging solutions for various commercial scenarios. These EV charging stations can be flexibly deployed according to your site needs, with customizable configurations to match your operation requirements. If you are looking for commercial EV chargers for sale for your commercial charging project, contact our team today to get a tailored solution and detailed quotation.
